| Genset Specification |
| Genset Prime Rating (kVA) * |
250 |
320 |
| Genset Prime Rating (KW) |
200 |
256 |
| Phase / Voltage (V) |
3 / 415 |
| Power Factor |
0.8 (lagging) |
| Current (A) |
348 |
445 |
| Frequency (Hz)& RPM |
50/1500 |
| Governing class |
G2 as per ISO 8528 Part V |
| Starting system |
24 V DC Elec |
| Fuel tank capacity |
575 |
575 |
| Canopy dimensions w/o silencer (mm) (L x W x H) approx. |
4600 x 1700 x 2025 |
4800 x 1700 x 2025 |
| Genset Weight (kg) approx. |
3700 |
3950 |
| Engine Specification |
| Make / Series |
Mahindra mPower |
| Engine Model |
mPower63105G |
mPower63905G |
| Rated Power at 100% Load @ 1500 RPM (HP) |
310 |
390 |
| Aspiration |
Turbocharged Aftercooled |
| No. of cylinders |
6 |
| Bore x Stroke (mm) |
116.6 x 146.1 |
| Displacement (Lit) |
9.3 |
| Alternator |
| Enclosure Type |
IP23 |
| Voltage regulation |
±1% |
| Class of insulation |
Class H |
| Maximum Unbalanced Load across Phases |
25% |
Above specifications are subject to change without prior notice due to continuous product improvements.
All engines & alternators confirm to respective IS standards
All the genset specifications are as per ISO 8528 standard
* For Standby duty, contact Powerol authorized representative
All specifications are at standard NTP operating conditions
All the above gensets conform to the latest CPCB norms of <75 dbA
